Product Overview

The PS40-1 is part of Potter’s PS10 Series of pressure-actuated switches, engineered to detect waterflow conditions in various fire sprinkler system configurations, including wet pipe systems with alarm check valves, dry pipe, preaction, and deluge systems. It can also function as a low-pressure supervisory switch, with an adjustable range between 4 and 15 psi (0.27–1.03 BAR).

Built with a durable die-cast enclosure and designed for both indoor and outdoor installations, the device meets key industry certifications such as UL, cUL, CSFM, FM, and LPC. The PS40-1 activates on pressure decrease at 30 psi (2.1 BAR) and operates reliably within a pressure range of 10–60 psi (0.7–4.1 BAR). Its rugged construction and NEMA 4/IP55 environmental rating ensure dependable performance across diverse system conditions.

Key Features

UL, cUL, CSFM Listed; FM and LPC Approved; NYMEA Accepted; CE Marking Pending
Operates on pressure decrease at 30 PSI (2.1 BAR)
Adjustable supervisory range: 4–15 PSI (0.27–1.03 BAR)
Compatible with wet, dry, preaction, and deluge sprinkler systems
Pressure operating range: 10–60 PSI (0.7–4.1 BAR)
Maximum system pressure: 300 PSI (20.68 BAR)
Differential:
- ~1 lb at 10 PSI (0.07 BAR)
- ~4 lbs at 60 PSI (0.28 BAR)
Dimensions: 3.78" W x 3.20" D x 4.22" H
Enclosure:
- Die-cast cover with textured red powder-coat finish, rain lip, and single cover screw
- Die-cast base
- NEMA 4/IP55 rated for indoor/outdoor use
Pressure connection: Nylon 1/2" NPT male
Conduit: Two 1/2" knockouts; isolated switch compartments for mixed voltages
Switch Contacts:
- One SPDT (Form C)
- Rated 10.1A at 125/250VAC and 2.0A at 30VDC
Temperature range: –40°F to 140°F (–40°C to 60°C)
Tamper-resistant cover with keyed fastener (key included)
Suitable for NFPA-13D, NFPA-13R, and NFPA-72 applications

52-630-1-001P TYCO
